Pentair System:3™ PLD Series 72 Sq Ft Modular D.E. Filter
The Pentair System:3™ PLD Series 72 Sq Ft Modular D.E. Filter (S7MD72) brings the proven System:3 modular technology to D.E. filtration — delivering the finest pool water clarity with dramatically simplified maintenance. When cleaning is needed, simply remove the filter lid and hose off the module in place. No grid assembly teardown. No complex disassembly. The balanced flow design maintains a constant D.E. cake across the entire module for full optimization and longer cycles between cleanings.
Sta-Rite by Pentair. Dura-Glas® two-piece glass-reinforced composite tank in matte black, Posi-Lok™ clamps for easy internal access, dual drain plugs with 1-1/2 inch NPT direct discharge port. Modular tank allows media changes without replacing the tank. ANSI Standard 50 certified. Backed by a 2-year warranty.
Key Features
D.E. Clarity — No Grid Teardown
D.E. filtration water quality with the easiest maintenance ever — remove the lid and hose off the module in place. No grid assembly disassembly required.
72 Sq Ft — Larger D.E. Capacity
Larger of the two System:3 Modular D.E. sizes (60 and 72 sq ft) — longer cycles between cleanings.
Balanced Flow / Constant D.E. Cake
Integral manifold ensures perfectly balanced flow and a constant D.E. cake across the full module surface for optimized filtration efficiency.
Superior Backwash Capabilities
Less manual cleaning required — superior backwash effectiveness extends service intervals.
Posi-Lok™ Clamps
Easy tool-free access to tank internals for module access and maintenance.
Dura-Glas® Two-Piece Tank
Industry-leading glass-reinforced composite resin in contemporary matte black — durable and attractive.
Dual Drain Plugs
Side plug with 1-1/2 inch NPT direct discharge plumbing option; bottom drain for full tank drainage.
Modular Tank / ANSI 50 / 2-Year Warranty
Media changeable without new tank. ANSI certified. Pentair 2-year residential warranty.
Who It's For
- Pool and spa owners who want D.E. water clarity without the complexity of traditional D.E. grid maintenance
- Anyone frustrated by annual D.E. grid teardowns who wants a dramatically simpler alternative
- Pools and spas where the 72 sq ft modular D.E. size is the right specification
- Existing Sta-Rite System:3 users who want the D.E. module option
Specifications
Performance
| Filtration Area | 72 sq ft |
| Filter Type | Modular D.E. (Single Module) |
Tank & Plumbing
| Tank Material | Dura-Glas® Glass-Reinforced Composite (Two-Piece) |
| Tank Color | Matte Black |
| Closure | Posi-Lok™ Clamps (Tool-Free) |
| Tank Port Size | 2 in NPT |
| Drain | Dual (Side 1-1/2 in NPT direct discharge + Bottom) |
Physical
| Product Weight | 150 lb |
| Shipping Dimensions | 26.75 × 26.75 × 41.5 in |
Approvals & Warranty
| Certifications | ANSI Standard 50 Certified |
| Warranty | 2 Years |
What's in the Box
- Pentair System:3 S7MD72 Modular D.E. Filter Tank
- D.E. Module
- User Manual
Note: Diatomaceous earth (D.E. powder) is not included and must be purchased separately.
Warranty
The Pentair System:3 S7MD72 comes with a 2-year manufacturer warranty. Clearflow Pool Supply is an authorized Pentair dealer and will assist with any warranty service needed.
Downloads
Frequently Asked Questions
How does the System:3 Modular D.E. differ from the System:2 PLD Series D.E. filter?
Both are Sta-Rite modular D.E. filters. The System:3 S7MD72 uses the larger Dura-Glas® System:3 tank platform at 72 sq ft — suited for larger pools — while the System:2 PLDE48 is the smaller compact design at 48 sq ft. The System:3 uses Posi-Lok™ clamps for access; the System:2 uses the Posi-Ring® closure. Both feature hose-off module cleaning without grid teardowns and carry a 2-year warranty.
Does this filter require backwashing?
The System:3 Modular D.E. has superior backwash capabilities that reduce the frequency of manual cleaning. When manual cleaning is needed, simply remove the filter lid and hose off the module in place — no grid assembly removal or complex teardown.
